This individual chrome plated toilet flush valve kit manufactured by leading washroom company Delabie is ideal for installation to control the flush of a single toilet without the need for a toilet cistern. It has a soft-touch operation.
It is designed to operate directly from a mains water supply (no need for a cistern) through a wall, into a service area or duct panelling (distance no greater than 150mm) which helps reduce vandalism. It offers either 3L/6L dual flush and can be adjusted to 2L/4L.
30 days free credit with
Buy Now, Pay Later, options at checkout
This individual chrome plated toilet flush valve kit manufactured by leading washroom company Delabie is ideal for installation to control the flush of a single toilet without the need for a toilet cistern. It has a soft-touch operation.
It is designed to operate directly from a mains water supply (no need for a cistern) through a wall, into a service area or duct panelling (distance no greater than 150mm) which helps reduce vandalism. It offers either 3L/6L dual flush and can be adjusted to 2L/4L.
Suggested uses and applications are within any public and commercial premises with 1 or more toilets where moderate to heavy use exists, including motorway services, schools, hospitals, offices, public toilets etc.
Connection to mains water supply means that there is no delay in subsequent flushing where the refill time for a cistern is too long. By comparison, a standard toilet cistern can take up to 60 seconds to refill. Ideal for locations experiencing high footfall.
Recommended water pressure is 2 to 4 bar (min pressure 1 bar). Inlet M3/4 - Outlet with connection for tube 32/26 diameter.
Function:
- Easy use by applying a smooth pressure on the push-button; helpful for children, disabled or elderly people
- Direct flush: Instantaneous flows (ensure sufficient dynamic pressure and correctly sized pipework)
- Automatic delayed shut-off. Water flows for 7 seconds
Features:
- Recessed time flow valve for direct flush:
- Chrome-plated metal wall plate Ø 195mm.
- Multipurpose recessing housing.
- Recessing depth can be adjusted from 0 - 20mm.
- 3L/6L dual flush can be adjusted to 2L/4L.
- Soft-touch operation.
- Vacuum breaker.
- Integrated stopcock and flow rate / flush volume adjuster.
- Solid brass body.
- Chrome-plated metal push-button.
- In-line inlet M¾".
- Outlet connection for PVC tube Ø 26/32mm.
- Acoustic level complies with European standard EN 12541 class II.
- Base flow rate: 1 L/sec.
- Suitable for rimless WC pans without flow rate regulation and suitable for people with reduced mobility.
- 10-year warranty
