100mm Axial Wall Mounted Extraction Fan With Timer And Shutters

£24.00 £20.00
459309

100mm Axial extraction fan with timer and shutters for the ventilation of bathrooms and W.C's, suitable for panel, wall or window mounting.

The shutter is controlled by a remote switch and will open and close one minute after the fan is switched on and off. The overrun timer will keep the fan operating at full speed for a pre-set time between 1 and 25 minutes after the switch is turned off. Factory setting is 15 minutes.Â

100mm Axial extraction fan with timer and shutters for the ventilation of bathrooms and W.C's, suitable for panel, wall or window mounting.

The shutter is controlled by a remote switch and will open and close one minute after the fan is switched on and off. The overrun timer will keep the fan operating at full speed for a pre-set time between 1 and 25 minutes after the switch is turned off. Factory setting is 15 minutes.

Features:

  • All non pull cord variants can be ceiling mounted
  • Suitable for wall or ceiling mounting
  • High Quality ABS mouldings with external gloss finish
  • Quiet Operation

Technical Specification:

  • Meets the requirements of Building Regulation Document F.
  • IP44 rated, BEAB Approved, and CE marked in accordance with all the relevant EEC Harmonised Directives.
  • Double Insulated, class II motor fitted with thermal protection
  • Hole Diameters: Window 105mm, Wall 115mm
  • Airflow: Panel Mount 88m3/hr, Window/Wall 69m3/hr

Product Range Details:

  • Rated Voltage 220-240v-50Hz
  • Rated Wattage 16W
  • Motor speed 2100rpm
  • Noise Level 30dB(A)
