Intamix Pro Thermal Mixing Valve (TMV) with Isolation Valves (22mm or 28mm)

Product Code:
6102-C
As low as £691.20 As low as £576.00

TheIntamix Pro range of thermal mixing valves (TMVs) is used as a group mixing valve where a fail-safe supply of warm water needs to be supplied to multiple taps or showers.

The Intamix Pro comes complete with factory fitted isolation unions, helping to save installation time. Available to suit either 22mm or 28mm pipework.

Read more

Two Inc

30 days free credit with Two Inc

Buy Now, Pay Later, options at checkout

TheIntamix Pro range of thermal mixing valves (TMVs) is used as a group mixing valve where a fail-safe supply of warm water needs to be supplied to multiple taps or showers.

The Intamix Pro comes complete with factory fitted isolation unions, helping to save installation time. Available to suit either 22mm or 28mm pipework.

Frequently used in commercial shower areas and changing rooms it is an ideal solution where building managers and owners need a consistent and stable water temperature across multiple outlets. It achieves this despite any variations in the water supply pressure or flow rate.

Features:

  • Thermostatic protection
  • Tamper proof head
  • Single piece thermostatic cartridge construction
  • Automatic shut off in the event of hot or cold-water failure
  • High flow rate, low pressure drops
  • Adjustable outlet temperature
  • Temperature stability ± 2°C
  • Technical Data:
  • Temperature range: 30 to 65 ̊C
  • Max. working pressure: 14 bar – Static; 5 bar - Dynamic
  • Min. working pressure: 0.2 bar
  • Max. inlet temperature: 85 ̊C
  • Max. inlet ratio (H/C or C/H): 2:1
  • Minimum flow rate required to maintain stability - 61022CPB: 8.3 l/min; 61028CPB: 13.0 l/min
  • Connections: 22mm and 28mm compression for copper pipe

Product Codes:

61022CPB: Intamix Pro V 22mm with isolating unions
61028CPB: Intamix Pro V 28mm with isolating unions
